Omnibus F4 Fireworks v2 (OSD/PDB/BEC/ FLASH/CURR/BARO/TLM)

Availability:
Waiting for stock
Product Code:
Omnibus Fireworks V2
Reward Points:
50
79.99лв. 68.99лв.
Price in reward points: 7999

You save 11.00лв.

5/5 (1 reviews) Write a review
Write a review

Omnibus F4 Fireworks – Final v2 version

ALL IN ONE – All new Omnibus F4 Fireworks. Great new features like soft mounted ultra fast gyro, Pro-grade PDB, 1A BEC, BAROMETER, Digital Current Sensor, Blackbox Data Flash, Betaflight OSD and easy telemetry pads for 32bit BLHeli_32 or KISS escs. One fixed inverter on SBUS.



- ICM20608 (32Khz). Same as the “super secret” RF1 gyro. Soft mounted. Replaceable with MPU6000 (option).
- Camera Control Pads
- 1x fixed signal invertor on SBUS
- PDB (up to 280A)
- Built in digital current sensor
- Build-in 1A 5V BEC
Build-in 1A 8V BEC with LC Filter (for cam and vtx)
- BLHeli32/Kiss ESC Telemetry pads
- Digital Current Sensor (А) – No Calibration Needed

- F4 MCU (
STM32 F405 168mhz)
- LC video filter (800mah max on camera)
- Barometer
- Betaflight OSD
- 2x more hardware UART ports compared to OmnibusF4SD target

Power: VBAT
Target:
OMNIBUSFW
SBUS Invertor: UART1
PPM: Use SBUS pin

ESC Telemetry: UART4
I2C: UART3
Spare UART: 2,6

Amperage Meter Scale: 175 (digital sensor)
User MANUAL: Download

AirBot 100% GENUINE
